White Color Conveyor Belt

Features:

White conveyor belt, consisting of cotton, nylon, polyester and other fabrics, with or without a covering layer outside the core. Examples of the covering layer can be divided into rubber type (including rubber-plastic type) and plastic type. The name of the light belt can be smooth, and there can also be various patterns of deep and shallow patterns or transverse strips, partitions and ripple edges. The transmission surface can also be longitudinally positioned, and the light belt may be wrapped or cut.

Product Standard: HG/T 2818-1996 "Light Conveyor Belt" Strength Specification (N/mm) 80 100 125 160 200 250 315 400 Width Specification According to GB/T 4490-1994 Total Thickness Specification (mm) 0.50.8 1.01.6 2.0 3.0 4.0 5.0 5 6.6 8.0

Physical-inductive normal temperature function of rubber-type light cover: Tensile strength Mpa is not less than 10, elongation at break is not less than 300% after thermal aging (70 x 96h). Tensile strength Mpa is not less than 7, elongation at break is not less than 250% and elongation at break is not less than 10%. The elongation of longitudinal reference force is not less than 4% of interlaminar bonding strength (N/mm). The interlaminar uniformity of rubber-based covering rubber and cloth is not less than 2.0. The interlaminar uniformity of longitudinal sample cloth is not less than 2.4 after thermal aging (70 C *96h). The interlaminar uniformity of longitudinal sample cloth is not less than 3.2, and the minimum peak value of longitudinal sample cloth is not less than 2.7 important benefits. Used for: flat conveyor belt, inclined conveyor belt (inclined angle < 19 C), leftover conveyor belt, smoke cabinet bottom belt, electronic weighing belt, elevator belt (skirt edge, baffle or rake nail), incoming and outgoing belt, side belt company through ISO 9001-2000 certification, and has independent import and export rights, products have been sold to more than 50 countries around the world, won. We have obtained the certification from the international market. The domestic market is large-scale iron and steel enterprises, coal mines, ports, mines, cement, chemical industry, transportation machinery temporary support.

Food grade white conveyor belt is processed from natural rubber or synthetic rubber such as styrene-butadiene rubber and cis-butadiene rubber. Oil can penetrate into these rubber to dissolve accounts, resulting in reduced strength and other mechanical properties of rubber. That is to say, these rubber resists all kinds of oils and organic solvents. When conveying this kind of material, the oil will swell and corrode the covering glue on the surface of the belt body, resulting in the expansion and deformation of the covering glue area on the surface of the belt body, resulting in the decline of the physical and mechanical properties of the conveyor belt and the shortening of its service life. The development of oil resistant conveyor belt is based on this demand. It is made of cotton canvas, polyester-cotton interwoven canvas, nylon canvas, polyester canvas and other skeleton materials, processed through calendering, forming, vulcanization and other processes, and has good oil resistance.

Usage: Suitable for transporting oily materials and some working conditions where oiliness and chemical solvents may occur.

Acid resistant alkali white conveyor belt:Cotton canvas, polyester canvas and nylon canvas are used as skeleton materials, rubber-plastic blends are used for covering rubber, and inert materials with excellent acidity and alkalinity are filled. The belt has good elasticity, low volume change rate and high strength retention rate.

Application: Suitable for working environment in contact with acid and alkali, such as phosphate fertilizer manufacturing, seawater salt drying, covering rubber, rubber-plastic blending and filling inert material with excellent acid and alkali resistance, better performance than chloroprene rubber acid and alkali resistance conveyor belt.
